UHF TV Whitespace Antennas

UHF TV White space antennas have been developed to take advantage of global TV white space (TVWS) spectrum, which is becoming more accessible in most parts of the world as analog TV services are sunset. Mobile carriers are increasingly exploiting this spectrum band, which occupies the 470MHz to 786MHz range to deploy mobile services.

Our UHF antennas combine maximum power and efficiency and are specifically engineered to provide high-coverage, resilient, and reliable communications across the entire UHF TV White space spectrum band. Our range of antennas also provide superior non-line-of-sight (NLOS) performance for areas with rugged or forested terrain.

Our omnidirectional, yagi, and sector UHF TV White space antennas provide superior coverage and unrivaled performance in TVWS frequencies.

  • Private networks

  • Industrial internet of things (IIoT)

  • Fixed wireless access

  • Spectrum and capacity augmentation

product

Type

Min. Freq. (MHz)

Max. Freq. (MHz)

Gain (dBi)

Ports

Horizontal Beam Width

Polarization

TA-445-Y90-12-VH
Antenna Type - Yagi
Min. Freq. (MHz) - 400
Max. Freq. (MHz) - 490
Gain (dBi) - 12
TA-400-Y400-11-V
Antenna Type - Log Periodic Yagi
Min. Freq. (MHz) - 400
Max. Freq. (MHz) - 800
Gain (dBi) - 11
TA-427
Antenna Type - Yagi
Min. Freq. (MHz) - 403
Max. Freq. (MHz) - 430
Gain (dBi) - 12.1
TA-468-S232-11N-90D
Antenna Type - Sector
Min. Freq. (MHz) - 468
Max. Freq. (MHz) - 700
Gain (dBi) - 11
TA-468-S232-11-90V
Antenna Type - Sector
Min. Freq. (MHz) - 468
Max. Freq. (MHz) - 700
Gain (dBi) - 11
TA-470-0-90
Antenna Type - Sector
Min. Freq. (MHz) - 468
Max. Freq. (MHz) - 700
Gain (dBi) - 11
TA-470-O316-57NF-V
Antenna Type - Omni
Min. Freq. (MHz) - 470
Max. Freq. (MHz) - 786
Gain (dBi) - 5.0 - 7.0
Bridging the Connectivity Gap

The ‘digital dividend’ spectrum, as it is commonly referred to, is highly desired by mobile operators as its low frequency assures higher coverage ability compared to spectrum in higher frequency bands. In the United States, unlicensed radio transmitters were allowed to operate in white spaces from 2010, including for services such as unlicensed Wi-Fi networks.

Til-Tek’s antennas can be deployed for a wide range of TV white space applications, including for 3G/LTE broadband, Internet of Things (IoT) and Industry 4.0 applications. We are among the pioneers in the space of TVWS technology. Speak to us to learn more about TVWS licensing exemptions and how you can harness the potential of the digital dividend spectrum.
